Fully preloaded IOL injection system, designed to deliver without compromise. Unique patented Lock & Roll technology and MICS lens as part of the same design process; this combination has resulted in the smallest fully preloaded injector available (1.65 mm nozzle). RayOne Aspheric is an enhanced version of the tried-and-tested C-flex and Superflex platform, combined into a single 6 mm optic design.
Fully preloaded IOL injection system, designed to deliver without compromise. Unique patented Lock & Roll technology and MICS lens as part of the same design process; this combination has resulted in the smallest fully preloaded injector available (1.65 mm nozzle). RayOne Aspheric is an enhanced version of the tried-and-tested C-flex and Superflex platform, combined into a single 6 mm optic design.
Aberration-neutral technology for optimal visual quality and functional visual acuity in all light conditions.
RayOne Aspheric is designed with an aspheric anterior surface that creates no spherical aberration.
Studies have demonstrated that aberration-neutral technology:
- Offers improved contrast sensitivity compared with spherical IOLs
- Provides better low light level visual acuity than spherical IOLs
- Can offer more depth of field than aberration-negative IOLs by retention of the patient’s natural level of corneal spherical aberration6
- Are less susceptible to the effects of decentration than aberration-negative IOLs
- Twice as many patients* preferred the aberration-neutral IOL than aberration-negative
- Three times fewer reports of visual disturbances with the aberration-neutral IOL than aberration-negative
Advantages:
- Designed to deliver without compromise
- Aberration-neutral technology for optimal visual quality and functional visual acuity in all light conditions. RayOne Aspheric is designed with an aspheric anterior surface that creates no spherical aberration.
- Reducing dysphotopsia by design:
- Rayner’s enhanced square edge technology shows no general increase in glare from previous models without a square edge
- Low refractive index (1.46)
- 360° Optimised Barrier to reduce PCO:
Rayner’s 360° Amon-Apple enhanced square edge creates an optimum barrier to reduce epithelial cell migration including at the haptic-optic junction. Extremely low Nd: YAG capsulotomy rates, comparable with hydrophobic acrylic lenses with square-edge optics.
- Vacuole free material for a glistening free IOL
- Single piece IOL created from a homogeneous material free of microvacuoles
- Compressible material for delivery through a micro incision
- Excellent handling characteristics with controlled unfolding within the capsular bag
- Low silicone oil adherence
- Excellent uveal biocompatibility
- Hydrophilic acrylic material with low inflammatory response
- RayOne Aspheric with patented Lock & Roll technology for a smoother, more consistent rolling and delivery of the lens via micro incision
- RayOne Aspheric enhanced 6 mm optic
- Amon-Apple enhanced square edge for minimal PCO 1.7% at 24 months
- Zero glistenings
- Based on proven haptic technology for excellent stability
- Anti-vaulting haptic technology provides excellent fixation in the capsular bag:
-Superb centration – Average offset of only 0.08 mm 3 to 6 months after surgery
-Excellent rotational and torsional stability – 1.83° mean IOL rotation 3 to 6 months after surgery
- One solution for all your patients:
-Largest fully preloaded power range on the market
-Easy to use and efficient IOL delivery time
Description:
Fully preloaded IOL, hydrophilic, aspherical, monofocal, for 2.2 mm incision.
Material | Single piece Rayacryl hydrophilic acrylic |
Water Content | 26% in equilibrium |
UV Protection | Benzophenone UV absorbing agent |
UV Light Transmission | UV 10% cut-off is 380 nm |
Refractive Index | 1.46 |
ABBE | 56 |
Overall Diameter | 12.50 mm |
Optic Diameter | 6.00 mm |
Optic Shape | Biconvex (positive powers), Biconcave (negative powers) |
Asphericity | Anterior aspheric surface with aberration-neutral technology |
Optic Edge Design | Amon-Apple 360° enhanced square edge |
Haptic Angulation | 0°, uniplanar |
Haptic Style | Closed loop with Anti-Vaulting Haptic (AVH) technology |
Power Range |
-10.0 D to +7.0 D (1.0 D increments, inc. plano) +8.0 D to +30.0 D (0.5 D increments) +31.0 D to +34.0 D (1.0 D increments) |
Delivery System Type | Fully preloaded IOL injection system |
Incision Size | Sub 2.2 mm |
