Ultra glistening-free. Ultra smooth. Ultra stable. Using high performance hydrophilic RayOne system as a foundation, RayOne Hydrophobic has been designed so that surgeons can offer patients excellent visual outcomes whilst still being user friendly in the operating room.
Ultra glistening-free. Ultra smooth. Ultra stable. Using high performance hydrophilic RayOne system as a foundation, RayOne Hydrophobic has been designed so that surgeons can offer patients excellent visual outcomes whilst still being user friendly in the operating room.
Advantages:
RayOne Hydrophobic was born out of a desire to deliver a better operating room experience for surgeons and better visual outcomes for patients, by challenging the current hydrophobic IOL solutions available to them.
- Ultra glistening-free. An independent in-vitro study against four leading hydrophobic IOLs found our lens to be glistening-free and equivalent or superior to the other lenses.
- Suitable for all patients. Aberration-neutral technology for visual quality and acuity in all light conditions.
- Designed to minimise PCO. Thanks to our Amon-Apple 360˚ enhanced square edge and its natural bioadhesivity, our hydrophobic lens is designed to minimise the risk of PCO.
- Ultra smooth. Patented Lock & Roll system rolls the lens inside the injector for a single smooth movement into the eye, with minimal force needed.
- Ultra stable. Patented Cornerstone lens design ensures the IOL is perfectly balanced as it travels down the injector nozzle. Once in the eye, Rayner’s anti-vaulting haptics lock against the unique Cornerstone tabs for superb stability.
- Fully preloaded power range. -10.0 D to +32.0 D power range means only one IOL solution is needed for all your monofocal patients.
- Always ready to implant. Proprietary material is not dependent on the temperature within the operating theatre, so it arrives ready-to-use with no warming needed.
- Improved performance and quality. All hydrophobic acrylic IOLs absorb water once in situ within the eye, causing expansion in size. Our lens is supplied in 0.9% saline solution so that it is in an equilibrated state and dimensionally stable from manufacture to implantation – reducing the chance of undesirable post-implant lens movement.
- Up to 2.25 D of extended depth of vision (with 1.0 D offset)
- Superior intermediate vision when compared with standard monofocals
- Smoother, blended transition between the dominant and non-dominant eyes when compared with standard monofocals, maintaining binocular stereoacuity and reducing asthenopia
- High quality spectacle-free distance vision
- Reduced pupil dependency, for optimised performance under low light conditions
- Reduced sensitivity to decentration and tilt compared to other IOL designs
- Complements the eye’s natural positive spherical aberration
Monovision. Enhanced.
RayOne EMV was developed in collaboration with world renowned surgeon, Professor Graham Barrett, to specifically enhance patient outcomes achieved with monovision.
New fully preloaded IOL is designed with an aspheric anterior surface and unique inner optic zone which induces controlled positive spherical aberration to extend depth of field without compromising visual acuity under low-light conditions.
Description:
Fully preloaded IOL, hydrophobic, aspherical, monofocal, for 2.2 mm incision. RayOne Hydrophobic was born out of a desire to deliver a better operating room experience for surgeons and better visual outcomes for patients, by challenging the current hydrophobic IOL solutions available to them.Material | Single piece hydrophobic acrylic |
UV Light Transmission | UV absorption 10% cut-off is 385 nm |
Refractive Index | 1.51 |
ABBE | 43 |
Overall Diameter | 12.50 mm |
Optic Diameter | 6.00 mm |
Optic Shape | Biconvex (positive powers), Plano, Concave (negative powers) |
Asphericity | Posterior aspheric surface with aberration-neutral technology |
Optic Edge Design | 360° enhanced square edge |
Haptic Angulation | 0°, uniplanar |
Haptic Style | Cornerstone lens design with Anti-Vaulting Haptic (AVH) technology |
Power Range |
-10.0 D to +7.0 D (1.0 D increments, inc. plano) +8.0 D to +30.0 D (0.5 D increments) +31.0 D to +32.0 D (1.0 D increments) |
Delivery System Type | Fully preloaded IOL injection system |
Incision Size | Sub 2.2 mm |
